FDY-001L 125KHz LF RFID Card
We have the ability to produce your RFID cards in full colour digital print. No surface printing or thermal transfer – these cards are digitally printed directly on to the plastic core of the card and protected underneath the PVC laminate overlay.
Product Description
RFID contactless card, also called proximity card, with the chip of low frequency 125KHz, high frequency 13.56MHz, or ultra-high frequency 860~960MHz. Our contactless cards are available with an exceptionally wide variety of chips and each chip is optimized for ultimate readability.
What we have:
· Laser Printing / Silkscreen Printing Logo / Offset Printing.
· Magnetic Stripe: 2750oe hico, 4000oe hico, 300oe loco.
· Punching Hole, Silver/Gold Metallic, UV Logo, Signature Panel.
· Numbering: Thermal Number, UV Number, Jet Dot Number, Laser Number.
We can support more:
· Ability to Design different RFID antenna, in different RF protocol, and frequency.
· Research and design different encapsulation for special environments.
· Data encoding and encryption options.
· Transponder design base on correspond with customer reader.
· Individual process.
Specification
|
Materials |
PVC, PET, ABS, PET-G, etc. |
|
Chip |
TK4100, EM4200, T5577, F08, MIFARE 1K, MIFARE Ultralight, I CODE SLI, etc. |
|
Frequency |
LF(125KHz), HF(13.56MHz), UHF(860-960MHz) |
|
Standard |
ISO14443A, ISO15693, ISO18000-6C, etc. |
|
Dimension |
85.60 x 53.98mm (credit card size, CR80 or customization) |
|
Thickness |
0.3mm, 0.5mm, 0.6mm, 0.84mm (0.3mm to 1.5mm upon request) |
|
Craft |
Barcode, Scratch Off Panel, Signature Panel, Spray Number, Laser Number, Embossing, etc. |
|
Printing |
Offset Printing, Silk-Screen Printing |
|
Card Surface |
Frosted/Glossy/Matte Finishing |
|
ID Number Printing |
Jet Dot Printing/ Thermo Transfer/ Laser Engrave |
|
Application |
Membership Management, Access Control, Hotel, Transportation, Loyalty, Promotion, etc. |
|
Package |
1. 200PCS/Box, Box Size: 21.5*9*5.5CM |
窗体顶端
|
Chip Type |
Protocol |
Capacity |
Anti Collision |
Function |
|
Available 125KHz Chip |
||||
|
TK4100 |
/ |
64 Bit |
No |
Read Only |
|
EM4200 |
/ |
128 Bit |
No |
Read Only |
|
T5577 |
/ |
330 Bit |
No |
Read/Write |
|
Hitag 1 |
ISO 11784/5 |
2K Bit |
No |
Read/Write |
|
Hitag 2 |
ISO 11784/5 |
256 Bit |
No |
Read/Write |
|
Hitag S 2048 |
ISO 11784/5 |
2K Bit |
No |
Read/Write |
|
Available 13.56MHz Chip |
||||
|
F08 |
ISO14443A |
1KB |
No |
Read/Write |
|
Ntag213 |
ISO14443A |
180 Byte |
No |
Read/Write |
|
Ntag215 |
ISO14443A |
540 Byte |
No |
Read/Write |
|
Ntag216 |
ISO14443A |
924 Byte |
No |
Read/Write |
|
MIFARE® S50 |
ISO14443A |
1KB |
No |
Read/Write |
|
MIFARE® S70 |
ISO14443A |
4KB |
No |
Read/Write |
|
MIFARE® Plus |
ISO14443A |
2KB/4KB |
No |
Read/Write |
|
MIFARE® DESFire |
ISO14443A |
2KB/4KB/8KB |
No |
Read/Write |
|
MIFARE® Ultralight EV1 |
ISO14443A |
640 Bit |
No |
Read/Write |
|
MIFARE® Ultralight C |
ISO14443A |
1184 Bit |
No |
Read/Write |
|
I CODE SLI |
ISO15693 |
128 Byte |
Yes |
Read/Write |
|
Ti2048 |
ISO15693 |
2KB |
Yes |
Read/Write |
|
Available 860-960MHz Chip |
||||
|
Alien H3 |
ISO18000-6C |
512 bit |
Yes |
Read/Write |
|
Monza R6 |
EPC Class1 Gen2 |
96 Bit |
Yes |
Read/Write |
